HVLS industrial fan 9.8ft to 23ft (3m to 7m)
HVLS industrial fans can help to even the temperature between the ground and ceiling by improving the air circulation and helping you to save in energy and utility bills.
During winter the HVLS fan will help to evenly mix the warm air in the ceiling and create a more comfortable space.
In summer the HVLS is the best complement to air conditioning, bringing a better sense of coolness and more important saving energy and money for you.
Available in different customizable colors
Main features
Slow speed far reaching airflow.
Bigger output with less power.
Easy to install.
Lighter, more efficient and easier to mantain than other insdustrial fans.
Bearing require less mantainance and has longer life.
| Size | Air Volume | Rotation Speed | Weight | Input Power |
|---|---|---|---|---|
| 9.8ft (3m) | 5000 ㎥/min | 100 RPM | 67 kg | 0.4 kW |
| 16ft (4m) | 11450 ㎥/min | 10 - 78 RPM | 72 kg | 0.6 kW |
| 18ft (5m) | 12200 ㎥/min | 10 - 68 RPM | 77 kg | 0.7 kW |
| 20ft (6m) | 12800 ㎥/min | 10 - 60 RPM | 87 kg | 1.2 kW |
| 23ft (7m) | 14250 ㎥/min | 10 - 54 RPM | 92 kg | 1.5 kW |
Rated Voltage: 230V A.C.
Rated Frequency: 50/60 Hz
